Lava Terrain Tutorial

lavamat1

Hey everyone, Reecius here from Frontline Gaming to share the Lava FLG Mat terrain tutorial!

A lot of folks have been asking to see how we made the cool terrain on the Lava FLG Mat, and so here we are with a step by step on how to do it.

This is a SUPER easy process, requiring not much money or time to pull off, which is one of the reasons why I love it, haha. While this tutorial focuses on lava style terrain, it can easily be used to make rock formations for any theme or FLG Mat by simply changing the colors and adding some fun stuff such as flock, snow, etc.

Anywho, here’s what you’ll need:

  • Pink Insulation Foam. These can be purchased at pretty much any big hardware store like Home Depot or ordered online. They typically come in various sized panels, up to 4×8′ sheets, which is more than you’ll need for several tables, and are cheap, too. Be sure not to get the kind that has a metallic coat on one side, that doesn’t work for our purposes.

insulation-board

  • Hot Wire Cutter. These are pretty much a necessity for cutting insulation foam. Grab one and it’ll last you for many a terrain making projects to come as once you see how fun and easy it is to make terrain out of foam, you’ll likely do it again for other projects.

71j-vOEJRtL._SL1500_

  • Black Latex House Paint. This stuff rocks for terrain. It’s super strong and acts as both paint (duh!), a glue for the sand, and a sealer to protect the foam from chipping.

download

  • Sand. You’ll use this for a ton of modeling projects from basing minis, to coating terrain as we will do here, to basing terrain, etc. Awesome to have in your hobby arsenal. You can pick up some from a hardware store, or get modeling sand from a company like Frontline Gaming (although the quantities sold for scale modeling are often not enough for terrain projects).

Sand

  • Glue and/or Toothpicks. You can use a variety of glues from Elmer’s to Tacky Glue. Elmer’s is usually good enough but Wood Glue and Tacky Glue are quite a bit stronger. Also, Tooth Picks can be used to make very strong bonds in the foam, but are not necessary.

elmer's glue wood glue tacky glue tooth picks

  • Dark Blue and Light Grey acrylic paint: It doesn’t matter where you get the paint or what kind it is (we often use the cheap bottles of craft paint) but you want a dark blue and a light grey color to match the Lava FLG Mat. If you want to use this tutorial for other types of terrain, just vary the colors you use starting with a darker base color working up to a lighter shade for the final dry brush.

paint

  • Paint Brush and Dry brush. You’ll want a house painting brush for the latex paint, which you can get at any hardware store for a few bucks. You’ll also need a big, fat dry brush that is nice and sturdy. Get a BIG one, too, it makes the process go much faster over several pieces of terrain.

house paint brush

drybrush

Let’s do this!

2016-04-10 15.23.55

  • Step 1, get dat insulation foam! Break it into manageable sized pieces if you got a full sized sheet. To do this, score one side with a sharp knife and then break it in half on the opposite side. Be careful, when it snaps it can hurt your ears as it is crazy loud.

2016-04-10 15.24.03

  • Step 2, glue some of the pieces together into a thickness that your hot wire cutter will fit around. If you want to build bigger objects than your hot wire cutter can fit around, you’ll have to cut them out from another stack of foam and then layer it onto the first, which is actually quite easy to do. The foam should be nice and flat which will create an even stack. I usually glue them together at this point and leave them to dry, but you can also use toothpicks to attach one level to another by poking it into one piece and then impaling the next on top of that. This makes the hills crazy strong but it not necessary.

2016-04-10 15.24.52

  • Step 3, plug in your Hot Wire Cutter and let it warm up. Once it’s nice and hot, go to town cutting out the shapes for the rock formations. Let your imagination go crazy, you can do all kinds of fun stuff like spires, rock clusters, arches, etc. Go nuts!

2016-04-10 15.26.26

  • Be sure to cut the foam in a ventilated area as the fumes are bad for you. If not, you risk going crazy like me in this picture!

2016-04-10 15.29.48

  • Step 4, once you’ve got the rock cut out, it’s time to get ready to paint the base coat on!

2016-04-10 15.31.19

  • Step 5, grab your house painting brush and slap a thick coat of paint on that little bugger. Really slop it on, you want the excess paint to hold the sand in the next stage.

2016-04-10 15.33.03

  • Step 6, snag that sand! We have a lot in the picture below because we’re always working on terrain projects. You probably won’t need this much for personal projects.

2016-04-10 15.34.08

  • Step 7, pour sand onto the still wet paint of your nifty rock, and it will stick right to it. Tap off any excess on to your drop cloth/paper/plastic bag and pour it back into the sand bucket.

2016-04-10 15.36.38

  • Step 8, at this point, you’ll want to let it dry overnight or at least for an afternoon. Once the paint has dried, tap off any excess sand and then grab your paint, again! Time for the second coat.

2016-04-11 06.01.22

  • Step 9, again, apply a thick coat. If you don’t, when the paint dries and shrinks down, sand will show through. The second coat of paint seals in the sand and makes the terrain piece quite sturdy. You’ll again want to wait for it to completely dry. We usually make terrain like this in big batches for several tables at a time to increase efficiency.

2016-04-12 10.27.57

  • Step 10, grab your dry brush and apply the first coat of dark blue paint. I used Kantor Blue, but you can use any dark blue.

2016-04-12 11.00.50

  • Step 11, apply your second layer of paint, this time very lightly. I used Administratum Grey (but again, you can use any light grey paint) to create a strong contrast with the deep blue and black of the base. This really makes it pop on the table!

2016-04-12 11.01.31

And you’re done! Easy peasy. You can knock out an entire table’s worth of terrain in a weekend, putting in just an hour or so per day into it. If you want to use these same techniques for rock formations for other FLG Mats, it is mega easy to do. Just alter the colors of paint you use. For desert, go with browns and tans, for grass, stick with browns and add green flock, for snow or even urban, use light blue or grey latex paint instead of black to apply and seal the sand, and then dry brush it with light greys and white, possibly gluing on some snow flock.

Simple, fast, affordable and great looking. Win!

Tags:

About Reecius

The fearless leader of the intrepid group of gamers gone retailers at Frontline Gaming!

13 Responses to “Lava Terrain Tutorial”

  1. gvcolor April 13, 2016 5:56 pm
    #

    Nice work and a great hobby how-to!

    • Reecius
      Reecius April 13, 2016 6:31 pm
      #

      Thanks! Glad you enjoyed it.

  2. bigpig April 13, 2016 9:56 pm
    #

    Thanks for posting. See, this is what I guessed you were using, but wasn’t sure. I haven’t had as much success as you guys have with this foam. I used it for my glacier bits on my Alpine map, but have issues when trying to stack and glue the pieces. How do you get around the lines visible from the different levels? Is the thick base coat paint you are using enough to camouflage it? or does the layer of sand do the trick?

    • Reecius
      Reecius April 14, 2016 8:50 am
      #

      I have found that if you cut into the foam at the joins, it creates a smooth join, and you really need to slop on that paint. A thick coat covers up a lot of errors. The sand and the second coat of paint really finishes it off.

      If you hunt online you can actually find very thick sheets of insulation foam which allows you to avoid the joins all together.

  3. xthexclincherx April 14, 2016 4:33 am
    #

    The hot wire cutter is brilliant! I’ve never made terrain before but I’m glad I saw this before breaking out the ol’ hacksaw… that would have been a nightmare!

    Great write-up!

    • Reecius
      Reecius April 14, 2016 9:12 am
      #

      Yeah, the hot wire cutter is pretty much mandatory when working with foam, it’s the tool for the job.

      Glad you liked the tutorial!

      • westrider April 14, 2016 12:39 pm
        #

        I did my Chaos VSG with a kitchen knife, and I’m still finding little shreds of pink foam all over the place 3 months later. Def picking up a hot wire cutter before I try something like that again.

  4. CWDub April 14, 2016 4:42 am
    #

    FINALLY. 😀

    Looks like I’ll be ordering one of these FAT mats this week, didn’t want to play it without terrain!

    • Reecius
      Reecius April 14, 2016 9:11 am
      #

      Yeah, sorry for the delay on this, I was buried with trying to fix the site. Glad you enjoyed the tutorial and have fun making terrain for your Lava mat!

  5. Toranagaaa April 14, 2016 2:16 pm
    #

    Another fun thing to do (if you wanna get real crazy!) is take a soldering torch or a lighter and BURN the foam. It melts into really interesting organic forms in the polyisocarbonate insulation, just like lava rock. Be careful not to burn yourself, and you absolutely must do it outside as the fumes are horrible. I pulled this trick a lot in architecture school when making building mock-up models – the profs thought my designs were so radical =p

    • Reecius
      Reecius June 6, 2016 6:23 am
      #

      Yeah, that works quite well! Great suggestions.

  6. Vito June 6, 2016 4:54 am
    #

    Awesome tutorial, Reece. Just made an entire table of terrain for our tournaments. Gonna take it even further making these for the desert and snow tables we have. Thanks for the terrain hack, brotha.

    • Reecius
      Reecius June 6, 2016 6:22 am
      #

      Happy to help, brotha!
